Saxsons Moving Laser Positioning SystemMotorised Red 635 nm — ±0.2 mm · DICOM 3.0/RT Integration
Saxsons own-brand movable laser positioning system for precise patient positioning in radiotherapy. Red 635 nm Class II laser source, ±0.2 mm accuracy, line width < 1 mm at 3–5 m. Available in one-axis, three-axis or five-axis movement configurations driven by exactitude linear guide rails with linear-coding closed-loop feedback. Control via computer, WiFi or manual control box. DICOM 3.0/RT compatible — virtual iso-centres flow from any standard TPS straight to the laser positioning. Designed and manufactured in India by Saxsons Healthcare Pvt. Ltd.
Key Features
- Designed and manufactured in India by Saxsons Healthcare Pvt. Ltd. — Saxsons own-brand movable laser system
- Red 635 nm Class II laser source — high-brightness operation under typical clinical lighting
- Line width < 1 mm at 3–5 m projection distance — sharp, narrow line at the patient surface
- Positioning accuracy ±0.2 mm — five-fold tighter than the AAPM TG-142 stereotactic-class default
- Movement configurations: one-axis, three-axis or five-axis — match the configuration to the room geometry and clinical workflow
All Features
- Designed and manufactured in India by Saxsons Healthcare Pvt. Ltd. — Saxsons own-brand movable laser system
- Red 635 nm Class II laser source — high-brightness operation under typical clinical lighting
- Line width < 1 mm at 3–5 m projection distance — sharp, narrow line at the patient surface
- Positioning accuracy ±0.2 mm — five-fold tighter than the AAPM TG-142 stereotactic-class default
- Movement configurations: one-axis, three-axis or five-axis — match the configuration to the room geometry and clinical workflow
- Exactitude linear guide rails with linear coding closed-loop feedback — the motorised drive arrives at commanded coordinates within the ±0.2 mm tolerance every time
- Three control modes: computer (workstation), WiFi (tablet / wireless terminal) or manual control box (physical pendant)
- Compatible with all DICOM 3.0/RT treatment planning systems — virtual iso-centres flow from the TPS straight to the laser positioning system
- Friendly operator interface — minimal training required for radiation-therapist routine use
- Suitable for CT-simulator patient marking, virtual iso-centre tattooing and treatment-vault patient setup
- Operates from standard mains power (220–240 V AC, 50 Hz) — typical Indian-clinic power profile
- CDSCO medical-device import registration supplied — the laser is a passive Class II red-laser accessory; no AERB licence is required for the device itself (the linac facility carries its own AERB licence separately)
- Commissioning service available — Saxsons installation team aligns the laser system against the CT-simulator iso-centre and provides the acceptance-test documentation
- Annual position-reproducibility verification service available
Technical Specifications
| Manufacturer | Saxsons Healthcare Pvt. Ltd. (designed and manufactured in India) |
| Laser source | Semiconductor laser, 635 nm red, Class II |
| Line width | < 1 mm at 3–5 m projection distance |
| Positioning accuracy | ±0.2 mm |
| Movement configurations | One-axis, three-axis or five-axis (configurable to room geometry) |
| Drive mechanism | Exactitude linear guide rails with linear coding closed-loop feedback control |
| Control modes | Computer (workstation) · WiFi (tablet / wireless terminal) · manual control box (physical pendant) |
| TPS integration | Compatible with all DICOM 3.0/RT treatment planning systems |
| Intended use | CT-simulator patient marking; virtual iso-centre tattooing; treatment-vault patient setup |
| Power supply | 220–240 V AC, 50 Hz; typical Indian clinical mains |
| Compliance framework | AAPM TG-142 / TG-179 patient-positioning laser expectations; the laser QA record feeds the linac-facility QA dossier reviewed at the annual AERB linac-facility inspection |
| Regulatory status (India) | Passive Class II red-laser accessory; imported under CDSCO Medical Devices Rules 2017 — no AERB licence needed for the device itself |
| Services included | Saxsons installation + commissioning + acceptance-test paperwork; optional annual position-reproducibility-verification visit |
Applications
Motorised DICOM-driven positioning — TPS to patient skin
DICOM 3.0/RT TPS workflow
The treatment planning system exports the virtual iso-centre in DICOM RT. The moving laser system reads the DICOM coordinates and drives directly to the planned position — no manual coordinate entry, no transcription error.
CT-simulator patient marking
Radiation therapist loads the TPS plan, presses go, watches the lasers drive to the planned iso-centre on the patient surface, marks the patient. The ±0.2 mm reproducibility means the same marks land in the same place every time.
Virtual iso-centre tattooing
Many plans use a virtual iso-centre offset from the patient surface. The 3- or 5-axis configuration positions the cross-hair at any offset point; tattoo the patient at that exact location.
Five-axis SBRT setup
Stereotactic body radiotherapy plans often use complex multi-axis iso-centres. The five-axis configuration handles non-orthogonal coordinate systems without requiring patient re-orientation on the couch.
Re-simulation mid-treatment
Patient anatomy changes (weight loss, oedema, gas filling) often require re-simulation. The moving system marks the new iso-centre without requiring physical adjustment of fixed lasers in the room.
Multi-modality CT-sim
A CT-sim room used for both megavoltage planning and brachytherapy planning needs flexible laser positioning. The same system serves both workflows — different iso-centre locations driven from the same control interface.
Why Saxsons Moving Laser Positioning System?
±0.2 mm accuracy is five times tighter than the AAPM TG-142 stereotactic-class 1 mm threshold. Same patient marked the same way twice ends up in the same place within ±0.2 mm. The reproducibility that virtual iso-centre tattooing absolutely requires, and that SBRT / SRS planning workflows depend on.
The treatment planning system exports the virtual iso-centre in DICOM RT. The moving laser system reads the DICOM coordinates directly — no manual coordinate entry by the radiation therapist. The transcription-error class of failure is eliminated by removing the transcription.
A single-axis system for routine patient marking; a three-axis for standard radiotherapy workflows; a five-axis for stereotactic and complex-anatomy treatments. The same Saxsons engineering scales from the basic CT-sim to the SBRT-capable theranostic suite.
Catalogs & Resources
Saxsons own-brand product reference. Contact Saxsons for installation scheduling, commissioning, CDSCO medical-device import documentation and India service support.
Saxsons own-brand · Variant brochure
Request the full Saxsons Moving Laser Positioning System variant brochure
The detailed variant matrix, dimensions, accessories and AERB import documentation are not published on this page. Tell us who you are and a Saxsons sales engineer will email the brochure to your institutional address within one working day.
Brochure dispatch is reviewed by a sales engineer before sending — we may verify by phone.
Saxsons Moving Laser Positioning
More for this product
Each card opens a focused post for a specific specialty — peer-reviewed evidence and clinical workflow, written for the persona you select.
FAQ
Moving laser positioning — questions we hear from Indian radiotherapy teams
Why virtual-isocentre CT-sim workflows need motorised lasers, what ±0.2 mm reproducibility buys for SBRT/SRS planning, how DICOM integration removes transcription error, and how to pick 1 / 3 / 5-axis configuration.
Q.Why do CT-simulator marking workflows need moving (motorised) lasers rather than fixed lasers?
A fixed laser projects one alignment reference — the machine isocentre. But a treatment plan often uses a virtual isocentre offset from the CT-simulator isocentre — the tumour position is not necessarily at the machine centre. On a fixed-laser system the therapist has to physically move the patient on the couch until the tumour lies at the isocentre, then tattoo. A moving laser drives to the virtual-isocentre coordinates from the TPS and marks the tumour position directly on the patient without shifting them — the mark lands at the exact planned coordinates.
Q.How does ±0.2 mm positioning accuracy translate into real clinical benefit?
AAPM TG-142 stereotactic-class laser tolerance is 1 mm. The Saxsons moving laser delivers ±0.2 mm — five times tighter. The reproducibility that virtual-isocentre tattooing absolutely requires — same patient marked the same way twice ends up in the same physical location within ±0.2 mm — is what SBRT and SRS planning workflows depend on for their setup-error budget. Under-tolerance lasers force the planning margin to expand to swallow the alignment uncertainty.
Q.What does DICOM 3.0/RT integration remove from the CT-sim workflow?
On a manual-entry moving-laser system the therapist reads the virtual-isocentre coordinates from the TPS screen, types them into the laser controller, drives the laser and marks the patient. Every transcription is a potential error source. DICOM 3.0/RT integration exports the virtual-isocentre coordinates from the TPS directly to the laser system — no manual entry, no transcription error. The class of error that comes from typing wrong numbers is eliminated by removing the typing.
Q.When does the department need 1-axis vs 3-axis vs 5-axis configuration?
Single-axis handles routine patient marking where the tumour lies in the coronal plane. Three-axis covers standard radiotherapy workflows where the virtual isocentre needs X / Y / Z translations. Five-axis handles stereotactic SBRT and SRS plans with complex multi-axis iso-centres and non-orthogonal coordinate systems. Configure to your treatment complexity — you don't need to buy the five-axis if the workflow is routine IMRT.
Q.How is the moving laser system supplied and supported in India?
Distributed across India by Saxsons Group. Supply covers the movable laser platform, axis configuration (1 / 3 / 5), DICOM integration with the department's TPS, installation, commissioning against the room isocentre and optional annual position-reproducibility-verification service. Passive Class II red-laser accessory — no AERB licence required for the device itself; CDSCO medical-device import registration handled by Saxsons.
