Saxsons own-brand tungsten-alloy vial shield family — high-density, compact-chassis shielding for the dispensing bench. Three tiers cover SPECT routine dispensing (5 mm, slide lock, 30 cc vial), PET routine dispensing (20 mm, 3-part body + lid + magnetic top cap, 15 cc vial) and high-activity PET / Lu-177 theranostic dispensing (30 mm, 2-part cap + base, 30 cc vial). Tungsten's high atomic number (Z = 74) and high density (≈ 19.3 g/cm³) deliver high per-millimetre attenuation — the chassis wall stays thin, the chassis stays small and light, the operator works through high-throughput PET shifts with less hand fatigue. Designed and manufactured in India in an ISO 9001 / ISO 13485 approved plant.
| Brand / build | Saxsons own-brand — manufactured in India by Saxsons Healthcare Pvt. Ltd., ISO 9001 / ISO 13485 approved plant |
| Shielding material | Tungsten alloy — high-density radiation-shielding grade |
| Shielding tiers | 5 mm (SPECT) · 20 mm (routine PET, 3-part) · 30 mm (high-activity PET, 2-part) |
| Construction styles | 1-part (5 mm tier) · 3-part body + lid + magnetic top cap (20 mm tier) · 2-part cap + base (30 mm tier) |
| Outer finish | SS over-finish on the tungsten body; wipe-down decontaminable; matt to reduce glare |
| Inner geometry | Bored vial cavity sized to the standard PET / Lu-177 vial (15 / 30 cc); custom vial-geometry inserts available |
| Closure styles | Slide Lock (5 mm SPECT tier) · Thread + Magnetic Top Cap (20 mm PET tier) · Thread Turn Lock between cap + base (30 mm tier) |
| Vial capacity range | 15 cc (20 mm tier) · 30 cc (5 mm and 30 mm tiers) |
| Engraving | Saxsons brand mark + shield-tier designation engraved on the chassis |
| Compatibility | Standard PET unit-dose and Lu-177 theranostic vial geometries; pairs with Saxsons Dose Cabinet, Lead-Lined Fume Hood and PET tungsten syringe shield |
| Compliance framework | AERB Safety Code for Nuclear Medicine Facility — extremity-dose protection; ICRP Publication 103 dose limits; ISO 9001 / ISO 13485 |
| Documentation | Per-batch material certificate, ISO quality-record pack |
Six worked dispensing workflows the family covers — pick the tier for the isotope and the throughput
5 mm tungsten tier for SPECT routine dispensing where the radiopharmacist wants the lighter, more compact chassis. Slide-lock closure for fast cycle time on cold-kit dispensing.
20 mm tungsten 3-part tier with magnetic top cap. The body holds the vial; the lid carries the needle hole; the magnetic top cap closes the needle access. Per-dispense, the operator pulls the top cap off magnetically, withdraws the dose, drops the cap back. The cap never leaves the shield surface.
20 mm tungsten 3-part tier (same as FDG). Per-generator elution + DOTATATE / DOTATOC / PSMA-11 labelling + 1–4 patient doses at 100–200 MBq. Magnetic top cap closure matches the PET FDG line.
30 mm tungsten 2-part tier for high-activity multi-dose source vials. The separate cap and base allow vial loading without rotating a screw-cap — important when the source vial sits on the bench for hours during the dispensing campaign and needs to be reopened for re-dispensing.
30 mm tungsten 2-part tier for Lu-177 DOTATATE / PSMA-617 / FAPI theranostic dispensing. Higher-energy contribution from internal pair production sits at 511 keV; the 30 mm tungsten tier delivers high per-millimetre attenuation for that photon line in a compact chassis.
Per-shift dispense count drives chassis weight cumulative load on the operator wrist. The tungsten family at 5 mm and 20 mm delivers high per-millimetre attenuation in a measurably lighter chassis — the wrist-load delta over a 30-dispense shift is real on the operator-fatigue log.
Tungsten's high atomic number (Z = 74) and high density (≈ 19.3 g/cm³) deliver high attenuation per millimetre of shielding wall. The chassis wall stays thin; the chassis stays small and light. For a hot-lab bench packed with shielded equipment, the smaller footprint matters; for the operator wrist-load over a high-throughput shift, the lighter chassis matters.
The 20 mm tier uses a three-part construction — body, lid with needle hole, magnetic top cap. Per dispense, only the top cap moves; the lid stays put on the body; the body stays put on the bench. The needle hole stays aligned to the vial septum; the operator never re-aligns the cap to the vial mid-shift. Three-part is the engineered match between dispensing ergonomics and shielding integrity.
The 30 mm tier uses a two-part construction — separate cap and base. Vial loading happens by lifting the cap straight off the base; no rotation, no thread engagement. For the high-activity source-vial workflow where the vial gets re-opened multiple times across the dispensing campaign, the cap-off motion stays simple and the cap stays clean.
Variant matrix
Three worked dispensing configurations across three tungsten shielding tiers and three construction styles. The per-workflow build sheet matches the tier to the isotope-energy ladder, the construction to the dispensing-line ergonomics, and the Accessories Matrix to the operator workflow.
Use-case configurations
| Use case | Tungsten | Construction | Vial | Notes |
|---|---|---|---|---|
| SPECT dispensing (Tc-99m, mid-energy SPECT isotopes) | 5 mm Tungsten | 1-part (slide lock) | 30 cc | Compact tungsten chassis for bench-ergonomic SPECT dispensing at high-throughput sites |
| PET dispensing (F-18 / Ga-68) — 3-part magnetic | 20 mm Tungsten | 3-part (body + lid + top cap) | 15 cc | Three-part construction: body holds the vial; lid carries the needle hole; magnetic top cap closes the needle access. Quick-release on the cap; one-touch open / close. |
| High-activity PET / Lu-177 — 2-part bench | 30 mm Tungsten | 2-part (cap + base) | 30 cc | Two-part construction: separate cap and base for easy vial loading / unloading. Shielded cap has the needle hole on top. Highest tungsten tier in the family. |
Closure styles
| Slide Lock | SPECT 5 mm tier — fast vial access for routine dispensing |
| Thread + Magnetic Top Cap | PET 3-part build — magnetic quick-release on the needle hole; one-touch open / close |
| Thread Turn Lock (cap + base) | High-activity PET 2-part build — separate cap and base; positive locking between the two halves |
Accessories Matrix
| Magnetic top cap on the needle hole | One-touch open / close for needle access; reduces per-dispense extremity exposure on PET high-throughput lines; cap stays on the shield throughout |
| Saxsons brand mark + size designation engraving | Inventory tracking; prevents wrong-shield pick-up at the dispensing bench |
| Tungsten + SS over-finish chassis | Tungsten core for radiation attenuation; SS over-finish for wipe-down decontamination compatibility and corrosion-resistance on the bench |
| Matt finish on the tungsten body | Reduces glare under hot-lab lighting; decontaminable surface; resists scratches from routine bench use |
| Anti-slip base | Stable footprint on the dispensing bench; resists vibration from adjacent equipment |
| Calibration certificate per consignment | Per-batch material certificate; AERB inspection-ready documentation |
| Custom vial-geometry inserts | Bespoke insert when the vial geometry differs from the standard 15 / 30 cc PET range; commissioned per-customer at site IQ |
| ISO 9001 / ISO 13485 quality-record pack | Per-batch quality records ship with every consignment; supports the AERB inspection dossier and the GMP file |
Per-batch material certificate ships with every consignment. Custom vial-geometry inserts and bespoke engraving are configurable on request and locked at site IQ / OQ.
AERB + ICRP + NIST references that anchor tungsten vial-shield selection. Contact Saxsons Healthcare for tier selection, vial-geometry confirmation and India pricing.
Indian regulatory framework for nuclear-medicine facility licensing including hot-lab shielding and extremity-dose-monitoring expectations.
Current ICRP framework defining the 500 mSv/year occupational extremity-dose limit.
Authoritative reference for photon attenuation coefficients in tungsten at 511 keV.
Saxsons Tungsten Vial Shield
Each card opens a focused post for a specific specialty — peer-reviewed evidence and clinical workflow, written for the persona you select.
Contact Saxsons Healthcare Pvt. Ltd. for tier + construction + vial-geometry configuration, per-batch material certificate documentation and pairing with the Saxsons Dose Cabinet, Lead-Lined Fume Hood and PET tungsten syringe shield — designed and manufactured in India.
