Saxsons Fixed Laser Positioning SystemSemiconductor Red 635 nm — Two Cross + One Linear Lasers
Saxsons own-brand fixed laser positioning system for accelerator, cobalt unit, simulator and CT-sim iso-centre indication. Each set comprises two cross lasers and one linear laser. Semiconductor red 635 nm Class II light source — high brightness, small line width (< 1 mm at 3–5 m), no bending, no imaginary light, stable without drift. ISO-centre adjustment precision < 0.5 mm. Designed and manufactured in India by Saxsons Healthcare Pvt. Ltd.
Key Features
- Designed and manufactured in India by Saxsons Healthcare Pvt. Ltd. — Saxsons own-brand patient-alignment laser system
- Each set comprises two cross lasers and one linear laser converging at the iso-centre
- Semiconductor red 635 nm Class II laser source — high-brightness operation under typical clinical lighting
- Line width < 1 mm at 3–5 m projection distance — sharp, narrow line at the patient surface
- ISO-centre adjustment precision < 0.5 mm — tighter than the AAPM TG-142 default of 2 mm and the stereotactic-class 1 mm threshold
All Features
- Designed and manufactured in India by Saxsons Healthcare Pvt. Ltd. — Saxsons own-brand patient-alignment laser system
- Each set comprises two cross lasers and one linear laser converging at the iso-centre
- Semiconductor red 635 nm Class II laser source — high-brightness operation under typical clinical lighting
- Line width < 1 mm at 3–5 m projection distance — sharp, narrow line at the patient surface
- ISO-centre adjustment precision < 0.5 mm — tighter than the AAPM TG-142 default of 2 mm and the stereotactic-class 1 mm threshold
- High brightness, small line width, no bending — straight projection across the working volume
- No imaginary light — single, unambiguous primary line; no ghost reflections
- Stable without drift — semiconductor diode design eliminates the thermal drift of older laser tube designs
- Advanced and convenient adjustment system — fine laser-beam adjustment at arbitrary degrees of freedom, dependently
- Suitable for accelerator (linac), cobalt unit, simulator and CT-sim iso-centre indication
- Operates from standard mains power (220–240 V AC, 50 Hz) — typical Indian-clinic power profile
- CDSCO medical-device import registration supplied — the laser is a passive Class II red-laser accessory; no AERB licence is required for the device itself (the linac facility carries its own AERB licence separately)
- Commissioning service available — Saxsons installation team aligns the lasers against the linac iso-centre and provides the acceptance-test documentation
- Annual alignment-verification service available — laser-vs-iso-centre cross-check at the annual physicist QA cycle
Technical Specifications
| Manufacturer | Saxsons Healthcare Pvt. Ltd. (designed and manufactured in India) |
| Laser source | Semiconductor laser, 635 nm red, Class II |
| Configuration | Each set: 2 cross lasers + 1 linear laser |
| Line width | < 1 mm at 3–5 m projection distance |
| ISO-centre adjustment precision | < 0.5 mm |
| Optical characteristics | High brightness; small line width; no bending; no imaginary light; stable without drift |
| Adjustment system | Advanced fine laser-beam adjustment at arbitrary degrees of freedom (dependently) |
| Intended use | Iso-centre indication for accelerator (linac), cobalt unit, simulator and CT-sim |
| Power supply | 220–240 V AC, 50 Hz; typical Indian clinical mains |
| Compliance framework | AAPM TG-142 / TG-179 patient-positioning laser expectations; the laser QA record feeds the linac-facility QA dossier reviewed at the annual AERB linac-facility inspection |
| Regulatory status (India) | Passive Class II red-laser accessory; imported under CDSCO Medical Devices Rules 2017 — no AERB licence needed for the device itself |
| Services included | Saxsons installation + commissioning + acceptance-test paperwork; optional annual alignment-verification visit |
Applications
Iso-centre indication for accelerator · cobalt · simulator · CT-sim
Linac iso-centre indication
Two cross lasers and one linear laser converge at the linac iso-centre. The cross projection marks the lateral patient axes; the linear projection marks the sagittal midline. Daily QA reads each axis independently against the radiation iso-centre.
Cobalt unit iso-centre
Same laser configuration on cobalt teletherapy units. The < 0.5 mm adjustment precision is tighter than the typical cobalt-unit gantry positioning tolerance, so the lasers do not contribute to the dominant setup error.
CT-simulator marking room
Patient marking using the fixed cross / linear projection. The advanced adjustment system fine-tunes the projection without requiring full re-alignment of the head when small position corrections are needed.
Conventional simulator
Conventional X-ray simulator iso-centre indication for older planning workflows. The system serves both digital CT-sim and conventional simulator workflows from one installed laser set.
Stereotactic / SBRT setup
The < 0.5 mm adjustment precision meets stereotactic-class patient-positioning expectations. Higher-precision SRS / SBRT treatments run without a separate dedicated laser system.
Multi-room facility standardisation
A multi-vault radiotherapy department installs the same Saxsons fixed laser system in every treatment room. Consistent alignment standard across rooms — patient-position transfer between machines (machine-down day, multi-site treatment) stays coherent.
Why Saxsons Fixed Laser Positioning System?
< 0.5 mm ISO-centre adjustment precision is tighter than the AAPM TG-142 stereotactic-class 1 mm threshold by a factor of two. The room is engineered for stereotactic treatments by default — no separate alignment cycle when SRS / SBRT patients arrive on the linac.
Class II semiconductor red 635 nm laser source — eye-safe under the IEC 60825-1 Class II classification, high-brightness against typical clinical lighting, and stable without drift compared to older gas-laser tube designs. The line is bright enough to read in the brightly-lit CT-sim and treatment-vault rooms.
Two cross lasers project orthogonal cross-hairs on the patient sides; one linear laser projects the sagittal midline. Three independent alignment axes converge at the iso-centre. Daily QA reads each axis separately — drift in one axis without the others is the first signal of a specific-mount issue.
Catalogs & Resources
Saxsons own-brand product reference. Contact Saxsons for installation scheduling, commissioning, CDSCO medical-device import documentation and India service support.
Saxsons own-brand · Variant brochure
Request the full Saxsons Fixed Laser Positioning System variant brochure
The detailed variant matrix, dimensions, accessories and AERB import documentation are not published on this page. Tell us who you are and a Saxsons sales engineer will email the brochure to your institutional address within one working day.
Brochure dispatch is reviewed by a sales engineer before sending — we may verify by phone.
Saxsons Fixed Laser Positioning
More for this product
Each card opens a focused post for a specific specialty — peer-reviewed evidence and clinical workflow, written for the persona you select.
FAQ
Fixed laser positioning system — questions we hear from Indian radiotherapy teams
Why every treatment room needs patient-alignment lasers, what < 0.5 mm precision buys against AAPM TG-142, why semiconductor Class II red is the contemporary default, and how the system is supplied across India.
Q.Why does every linac / cobalt / CT-sim room need a patient-alignment laser system?
The linac isocentre is a physical point in space defined by the intersection of the beam central axis and the couch rotation axis. The therapist cannot see it. Patient-alignment lasers project three orthogonal lines (two lateral cross-hairs + one sagittal midline) that meet at the isocentre, so the therapist can align the patient's tattooed marks to the same isocentre on every fraction. Without them, day-to-day setup drifts and the tumour walks out from under the plan.
Q.What problem does < 0.5 mm ISO-centre adjustment precision actually solve?
AAPM TG-142 sets the stereotactic-class laser-to-isocentre tolerance at 1 mm. Non-stereotactic default is 2 mm. The Saxsons fixed laser system delivers < 0.5 mm adjustment precision — tighter than the stereotactic threshold by a factor of two. Practically that means the room is engineered for stereotactic treatments by default; when an SRS or SBRT patient arrives on the linac, no separate alignment cycle is needed to drop the room into a stereotactic-class tolerance.
Q.Why semiconductor diode red 635 nm Class II lasers rather than older gas-tube designs?
Older gas-laser tubes drift with temperature and age — routine daily QA catches the drift, but the alignment cycle becomes frequent. Semiconductor 635 nm red Class II lasers are stable without drift and eye-safe under IEC 60825-1 Class II classification. The line is bright enough to read in the CT-sim and treatment-vault ambient lighting, and does not need a daily warm-up cycle before list start.
Q.Does the same system serve linac + cobalt + simulator + CT-sim rooms?
Yes. The fixed laser set (2 cross + 1 linear) is manufacturer-agnostic on the treatment platform — Varian TrueBeam / Halcyon / Ethos, Elekta Versa HD / Infinity, cobalt teletherapy units, conventional simulators and CT-simulators all use the same three-laser geometry. A multi-vault department standardises on one alignment reference across every room; patient position transfers between machines stay coherent.
Q.How is the fixed laser system supplied and supported in India?
Distributed across India by Saxsons Group. Supply covers the three-laser set, installation, commissioning against the room isocentre, acceptance-test documentation and optional annual alignment-verification service. Passive Class II red-laser accessory — no AERB licence required for the device itself; CDSCO medical-device import registration handled by Saxsons.
