Saxsons own-brand lead-lined fume hood — a configurable hot-lab workstation manufactured in India in an ISO 9001 / ISO 13485 approved plant. Lead-shielded enclosure (3 / 5 / 6 / 10 / 12 mm options) with a stainless-steel-lined work zone, counter-weighted clear acrylic sash, CE-marked motor driving an AMCA-certified centrifugal fan through an active-carbon (and optional pre-filter + HEPA + UV) filtration train. Configured per site SOP — choose the size, shielding, materials, filter pack and accessory fit-out that match the workflow. Minimum face velocity 0.5 m/s per AERB guidelines.
| Brand / build | Saxsons own-brand — manufactured in India by Saxsons Healthcare Pvt. Ltd., ISO 9001 / ISO 13485 approved plant |
| Lead shielding options | 3 mm · 5 mm · 6 mm · 10 mm · 12 mm (operator-selected per workflow) |
| External dimensions | Standard 51 × 25 × 55 in (L × W × H without stand); small / mid / large / compact variants — see variant matrix below |
| Inner work-zone (Std) | 42 × 18 × 29 in (Standard 51-in frame); 32.16 × 18.32 × 29.5 in (Small 41-in frame); 48 × 32 × 48 in (Large 58-in frame) |
| Inner material | Stainless steel — SS 202 (standard) or SS 304 (premium / heavier shielding builds) |
| Outer material | MS painted finish (standard); SS 202 or SS 304 (premium full-stainless builds) |
| Sash | Counter-weighted clear acrylic sliding sash; effortless open / close |
| Lighting | Fluorescent or LED work-zone lamp; control switch on external panel |
| Exhaust motor | CE-marked universal AC motor; on/off switch on external panel |
| Exhaust fan | AMCA-certified standard centrifugal fan; heavy-duty centrifugal blower on premium builds |
| Filter pack — standard | Active-carbon (charcoal) filter on the exhaust path |
| Filter pack — premium | Pre-filter + HEPA + active-carbon (optional UV light) — for higher-particulate / cleaner-room fit-outs |
| Face velocity | ≥ 0.5 m/s at the sash opening, verified at the time of shipping per AERB guidelines |
| Differential-pressure monitoring (option) | Negative-pressure sensor with 10″ PLC touch panel for live across-filter ΔP feedback; flags choke-state before face velocity drifts |
| Power connection | Indian power connection standard; export voltage variants on request |
| Stand | Frame stand standard; unshielded bottom-cabinet variant for routine supplies; stand-free benchtop variant for compact 39-in frame |
| Compliance framework | AERB Safety Code for Nuclear Medicine Facility, ISO 9001, ISO 13485, AMCA fan certification, CE-marked motors |
| Documentation | Site build sheet, IQ / OQ / PQ protocols, factory face-velocity certificate, AERB compliance paperwork, Saxsons-branded operator manual |
One cabinet family across Tc-99m, F-18, Ga-68, Lu-177 and I-131 dispensing workflows
Daily Tc-99m kit reconstitution and dispensing inside a 3–6 mm lead-shielded enclosure. Generator compartment variant houses the Tc-99m generator inside the cabinet; the dispensing line runs alongside without separate room shielding.
Per-patient [18F]FDG / [18F]NaF unit-dose dispensing from a transport vial. 5–6 mm shielding plus the optional 45 mm Capintec-type lead rings cover the 511 keV annihilation line at typical PET unit-dose activities.
10–12 mm shielding option for theranostic dispensing programmes — Lu-177 DOTATATE / PSMA-617 and Ga-68 generator elution. PLC + body-shield premium build adds operator-side dose-rate management for routine high-activity dispensing.
I-131 capsule dispense and oral-solution decant — active-carbon filter + optional HEPA captures volatile radioiodine on the exhaust before site-stack release.
Dose-calibrator ionisation-chamber-mount variant integrates an end-user-supplied dose calibrator inside the cabinet, with the display mounted externally. Removes a separate dispensing-bench footprint from the hot-lab fit-out.
Lockable cabinet, factory face-velocity certificate, daily anemometer log (when anemometer is fitted) and the AERB compliance paperwork pack — the cabinet ships ready for first-inspection sign-off and slots into the routine inspection dossier thereafter.
AERB Safety Code for Nuclear Medicine Facility expects a minimum 0.5 m/s face velocity at the sash opening on dispensing fume hoods. Every Saxsons-built cabinet ships with a factory-issued face-velocity certificate at the time of shipping, and the optional hot-wire anemometer keeps the operator within spec day to day.
Routine Tc-99m kit dispensing runs at 3 mm. Mid-activity F-18 / Ga-68 / Lu-177 dispensing runs at 5 / 6 mm. Theranostic high-activity prep runs at 10 / 12 mm. One cabinet family covers the whole NM activity range — choose the shielding tier for the workflow, not for the whole department.
Designed and built in India by Saxsons Healthcare Pvt. Ltd. in an ISO 9001 / ISO 13485 approved plant. Local manufacture cuts lead times, local engineering means site-specific build sheets, and the AERB compliance paperwork lands first time because the build is documented to the AERB framework.
Variant matrix
Five axes — size, shielding, material, filter pack and accessory fit-out. The site- specific build sheet locks the combination that matches the dispensing programme and the AERB licence; the same chassis family covers everything from a satellite-imaging probe bench to a theranostic high-activity prep room.
Size variants — external L × W × H (in)
| Frame | External (in) | Notes |
|---|---|---|
| Compact | 39 × 26 × 27 in | Probe / counter bench, side-station |
| Small | 41 × 23 × 51 in | Inner 32.16 × 18.32 × 29.5 in; entry / satellite hot lab |
| Standard | 51 × 25 × 55 in | Inner 42 × 18 × 29 in; the workhorse footprint |
| Standard+ | 52 × 25.7 × 55 in | Slight overhang option; pairs with optional anemometer |
| Mid | 54 × 27 × 57 in | Heavier shielding fit, deeper work zone |
| Mid+ | 56 × 30 × 52 in | HEPA + lead-rings + generator-compartment fit-out |
| Mid Premium | 58 × 34 × 55 in | PLC + body-shield premium build |
| Large | 58 × 38 × 73 in | Inner 48 × 32 × 48 in; high-throughput hot lab |
| Wide-low | 66 × 35 × 49 in | Lead-bricks front shielding + dose-calibrator bench |
Filter packs
| Standard | Active-carbon filter on exhaust; covers Tc-99m / F-18 routine dispensing |
| HEPA + Charcoal | Pre-filter + HEPA + active-carbon (+ optional UV light); for higher-particulate or cleaner-room fit-outs |
| Generator + Waste compartment | Integrated Tc-99m generator compartment + shielded waste compartment with HEPA filtration and lead-glass viewing |
Accessories Matrix
| Hot-wire anemometer | Live face-velocity readout for AERB 0.5 m/s sash check |
| Negative-pressure sensor + 10″ PLC touch panel | Across-filter pressure differential with PLC feedback; flags choke-state before face velocity drifts |
| Movable body shield with lead-glass window | External adjustable splash / line-of-sight shield for dispensing; integrates with the cabinet sash |
| Dose-calibrator ionisation-chamber mount | Internal mounting for an end-user-supplied dose calibrator with external display; eliminates a separate bench |
| Gamma-probe mount | Internal probe geometry for in-cabinet Tc-99m / F-18 wipe assay |
| Lead-rings (45 mm Capintec-type) | Dose-calibrator vial / syringe geometry shielding; matches standard counter geometries |
| Lead-bricks front-wall shielding | Supplementary shielding ahead of the dispensing line for high-activity work |
| UV light + LED work-zone lamp | Surface decontamination cycle + bright work-zone lighting |
Site-specific build sheet locks the size × shielding × material × filter × accessory combination per workflow. Each Saxsons-built unit ships with a factory face-velocity certificate, IQ / OQ / PQ protocols and the AERB compliance paperwork pack.
AERB + IAEA + AMCA references that anchor the lead-lined fume-hood design. Contact Saxsons Healthcare for the site-specific build sheet, IQ / OQ / PQ documentation and India pricing.
